Stäubli MC4-Evo 2 male connector 2.5 mm² PV-KST4-EVO 2A/2.5I
Original Stäubli Electrical Connectors MC4-Evo 2 male cable coupler (pin), type PV-KST4-EVO2A/2.5I, for photovoltaic connections. Designed for crimp termination of 2.5 mm² solar cables with an overall cable diameter from 4.7 to 6.4 mm.
The connector is mating-compatible with the MC4 product family, uses the MULTILAM contact system and is suitable for PV installations up to 1,500 V DC. The insulating component is included.
Technical specifications
Manufacturer: Stäubli Electrical Connectors
Product family: Original MC4-Evo 2
Type: PV-KST4-EVO2A/2.5I - male cable coupler (pin)
Connection system: 4 mm diameter
Conductor cross-section: 2.5 mm² / 14 AWG
Overall cable diameter: 4.7 to 6.4 mm
Stripping length: 4 mm
Termination method: crimping
Rated voltage: 1,500 V DC
Rated current: 39 A according to IEC 62852; 30 A according to UL 6703
Contact resistance: less than 0.2 mΩ
Ambient operating temperature: -40 °C to +85 °C
Degree of protection, mated: IP65 / IP68 (1 m, 168 h)
Degree of protection, unmated: IP2X
Contact material: tin-plated copper
Insulating material: polyamide, flammability class UL94-V0
